    High Temperature Industrial Limit Switches Thermoplastic Roller Lever Mental Cast

    Ask Lasest Price
    Brand Name : KJTDQ
    Model Number :
    Certification : CE,RoHS
    Price : $18.9-26.9
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 100000 pcs/mouths
    Delivery Time : 7-15 work days
    • Product Details
    • Company Profile

    High Temperature Industrial Limit Switches Thermoplastic Roller Lever Mental Cast

    KJT-XW Series High Temperature Limit Switch

    Quick details:
    Name:High temperature limit switch
    Model: KJT-XW
    Operating temp.: -25℃~350℃

    Specification:

    Rated Voltage(V)Noninductive Load
    (A)
    Inductive Load
    (A)
    Resistance LoadLamp LoadInductive LoadMotor Load
    NCNONCNONCNONCNO
    125 V AC1031.51052
    250 V AC521531.0
    480 V AC31.50.831.50.8
    600 V AC110.51.510.5
    8 V DC1063106
    14 V DC1063106
    30 V DC64364
    125 V DC0.80.20.20.80.2
    205 V DC0.40.10.10.40.1

    Model No.
    KJT-XW
    NameHigh Temperature Limit Sensor
    Rated current10 A 250 VAC
    Operation speed1 mm--2 m/sec
    Operating frequencyMechanical:120 operations/minute
    Electrical:30 operations/minute
    Contact resistance15 mΩ max.(initial value)
    Insulation resistance100 mΩ min.(at 500VDC)
    Dielectric strength1000VAC,50/60HZ for 1 minute between terminals of the same polarity
    2200VAC,50/60 HZ for 1 minute between currentcarrying and non-current carrying metal parts
    2200VAC,50/60 HZ for 1 minute between each terminal and ground
    Vibration10-55 HZ,1.5 mm double amplitude
    ShockMechanical durable:1000m/Sec2(about 100G'S);
    Malfunction(Misoperation):300m/Sec2(about 30G'S)
    Operating temperature-60ºC ~ +350ºC
    Operating humidityMax. 95% RH
    LifeMechanical:15,000,000 above
    Electrical:500,000 above
    Protection degreeIP 67
    Weight258 g
    LogoCustomized logo with Decal / Frosted / Print are available as request
    Payment term30% deposit in advance,70% before shipment,100% T/T in advance
    CertificateCCC,CE,ISO9001
    Design abilityWe can supply sample,OEM & ODM is welcome (Design,Engineering, Photographing,Sample, Production)

    Application:

    High temperature limit switch is widely used in steel mills, and the temperature can up to 350℃.

    Competitive Advantage:

    1) Double circuit type of limit switch
    2) Temperature up to 350 ºC, products are divided into high temperature 200 ºC and 350 ºC two specifications

    FAQ:


    Q: What's your warranty ? How about the quality of your sensors ?
    A: 18 mouths .
    We have the certification of ISO,CE,CCC.Our sensors can replace many famous brand sensors(BALLUFF,IFM,P+F,TURCK,OMRON,SICK,Contrinex,Schneider,KEYENCE,
    BANNER,BAUMER,AUTONICS,etc) You can provide us the date sheet and we check whether can produce.

    Q: What's your shipment method?
    A: We ship by Express, by air, by sea, by train. Normally we checked and compare, then provide customer the most proper shipment method.

    Q: What's about MOQ?
    A: First order MOQ=5 pcs (different type sensor has different MOQ)
