IP67 M8 Waterproof Connector Cable 4 Pin Female Straight Molded Cable

    Buy cheap IP67 M8 Waterproof Connector Cable 4 Pin Female Straight Molded Cable from wholesalers

    Buy cheap IP67 M8 Waterproof Connector Cable 4 Pin Female Straight Molded Cable from wholesalers
    • Buy cheap IP67 M8 Waterproof Connector Cable 4 Pin Female Straight Molded Cable from wholesalers

    IP67 M8 Waterproof Connector Cable 4 Pin Female Straight Molded Cable

    Ask Lasest Price
    Brand Name : KJT
    Model Number : Cable connector
    Certification : CE,RoHS
    Price : USD2.1-10.8 /pcs
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 50000pcs/mouths
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    IP67 M8 Waterproof Connector Cable 4 Pin Female Straight Molded Cable

    Waterproof Sensor Connector M12 4pin Female IP67 Connector Straight Molded Cable


    Specification:
    Connector locking system: Screw-locking
    Waterproof O-ring: FKM
    Insert: PA66+GF
    Female contacts: Phosphorus copper with gold plated
    Male contacts: Brass with gold plated
    Screw: Brass with nickel plated
    Termination: Riveting
    Over-mold: PVC/PU/TPU
    shell and contactCopper alloy
    Insulator and PG9 screwPlastic
    Cable clampCopper Alloy
    Contact PlatingGold plated
    Other Metal PlatingNickel Plated
    Electrical
    Rated Voltage60V
    Rated current4A/40°C
    Contact resistance8m ohm
    Rated impluse withstand voltage2500V
    Mechanical
    Connecting typeThread with M12
    Protection DegreeIP67
    Mechanical operation500 mating cycles
    Suitable cableOD:4mm-6mm/6mm-8mm

    Wire gauge (AWG): 22AWG or 24AWG
    Wire gauge (mm² ): 0.34mm² Or 0.25mm²
    Wire insulation: PVC
    Cable jacket: PVC/PUR
    Operation temperature: -25° C ~ +80° C or -40° C ~ +105° C
    M8 series connectors provides a wide range of metric for small sensors and actuators.The ingress protection is available and rated to IP 67, these connectors are ideally suited for industrial control networks where small sensors are required. Connectors are either factory TPU over-molded or panel receptacles supplied with sold-cup for wire connecting or with PCB panel solder contacts. Field attachable / mountable connector is also available for your choice.
    Our Service:

    To Be Your The Best Connection Expert
    1. Low cost but good quality in ip67 waterproof in locked condition with ISO9001 management under efficient service
    2. Provide free samples within 2 working days if it is normal product with existing tooling
    3.10 years quality assurance
    4. OEM, ODM are availaleb


    FAQ:
    Q: What's your warranty ? How about the quality of your sensors ?
    A: 18 mouths .
    We have the certification of ISO,CE,CCC.Our sensors can replace many famous brand sensors(BALLUFF,IFM,P+F,TURCK,OMRON,SICK,Contrinex,Schneider,KEYENCE,
    BANNER,BAUMER,AUTONICS,etc) You can provide us the date sheet and we check whether can produce.


    Q: Do you have different style ?
    A: We produce our own brand sensor(KJT),also provide OEM + ODM service.
